MIL-DTL-5882E
a. Individual inspection (see 4.3.1)
b. Sampling inspection (see 4.3.2)
4.3.1 Individual inspections. Each transmitter submitted for acceptance under contract
shall be subjected to the individual inspections specified in MIL-PRF-5350 and all tests specified
in 4.5.
TABLE I. Multi-purpose pressure transmitter scale error tolerances, ± psi.
TEST CONDITION
TEST POINTS (PSI)
0
10
20
25
30
40
50
Room Temperature
0.75
0.75
0.50
0.50
0.50
0.50
1.00
Low Temperature
Operational
1.25
1.25
1.25
1.25
1.25
1.50
1.50
High Temperature
Operational
1.25
1.25
1.25
1.25
1.25
1.50
1.50
Vibration (Post Test Operation)
1.00
1.00
1.00
1.00
1.00
1.00
1.25
Low Temperature Exposure
(Operational)
1.25
1.25
1.25
1.25
1.25
1.50
1.50
Room Temp. following Low
Temp. Exposure*
0.75
0.75
0.50
0.50
0.50
0.50
1.00
Room Temp. following High
0.75
0.75
0.50
0.50
0.50
0.50
1.00
Temp. Exposure*
Seasoning
1.00
1.00
1.00
1.00
1.00
1.00
1.25
Endurance
1.25
1.25
1.25
1.25
1.25
1.50
1.50
Power Supply Variation*
0.75
0.75
0.50
0.50
0.50
0.50
1.00
Salt Spray *
0.75
0.75
0.50
0.50
0.50
0.50
1.00
Suction and Overpressure
1.50
1.50
1.50
1.50
1.50
1.50
1.50
Shock (Post Test Operation) *
0.75
0.75
0.75
0.75
0.75
0.75
0.75
*NOTE: The tolerances shown are applicable unless allowable shifts in calibration have occurred
during preceding tests, in which case the tolerance of such preceding test shall apply.
4.3.2 Sampling. Sampling shall be as specified in MIL-PRF-5350.
4.4 Inspection conditions. Unless otherwise specified, the transmitter shall be tested in a
horizontal position with the pressure connection at the top.
4.5 Test Methods.
4.5.1 Scale error. The test points and tolerances for the error test shall be as specified in
Table I.
4.5.2 Friction. Tolerances for the friction test shall be as specified in Table II.
4
