MIL-PRF-5350G
c. Endurance (see 4.6.10)
d. Power supply variations (see 4.6.12)
e. Damping (see 4.6.13)
f. Overscale (see 4.6.14)
g. Low temperature (see 4.6.15)
h. High temperature (see 4.6.16)
i. Vibration (see 4.6.17)
j. Low temperature exposure (see 4.6.18)
k. Low pressure (see 4.6.19)
l. Extreme high temperature (see 4.6.20)
m. Acceleration (see 4.6.25)
n. Torque (see 4.6.28)
4.4 Test conditions. Unless otherwise specified in the acquisition document, all inspections
shall be performed in accordance with the test conditions described below, or as specified in
the acquisition document.
4.4.1 Standard atmospheric condition. Unless otherwise specified in the individual test
description, all tests shall be performed at ambient pressure and temperature.
4.4.2 Tapping. Unless otherwise specified in the individual test description, the transmitter
shall be tapped before testing to overcome friction.
4.4.3 Test voltage. Unless otherwise specified in the individual test description, the
transmitter shall be tested with the voltage and frequency specified in 3.5.5. The voltage
and frequency shall be maintained within 1% of the nominal value.
4.4.4 Standard production indicating unit. The transmitters shall be tested with a standard
production indicating unit with a maximum error of 0.5 degree.
4.5 Requirements cross-reference matrix. Table III provides a cross reference matrix of the
section 3 requirements tested or verified in the paragraphs below.
Table III. Requirements cross-reference matrix
Requirement
Verification
Requirement
Verification
3.2
4.2
3.6.11
4.6.20.2
4.6.1, 4.6.22,
3.4
3.6.12
4.6.28
4.6.23
3.5.1
4.6.26
3.6.13
4.6.6
3.5.2
4.6.1
3.6.14
4.6.2
3.5.3
4.6.1
3.6.15
4.6.3
3.5.4
4.6.1
3.6.16
4.6.7
3.5.5
4.6.12
3.6.17
4.6.13
3.5.6
4.6.11
3.6.18.1
4.6.8
8
