INCH-POUND
MIL-DTL-27189E
19 February 2008
Supersedes
MIL-I-27189D
15 October 1993
DETAIL SPECIFICATION
INDICATOR, PRESSURE, OIL
This document is inactive for new design after 24 March 1999.
This specification is approved for use by all Departments and Agencies of the Department of Defense.
1. SCOPE
1.1 Scope. This specification covers hermetically sealed, remote indicating, voltage ratio type integrally lighted,
oil pressure indicators.
1.2 Classification. Indicators shall be of the following types, as specified (see 6.2):
MS24576-1
Red lighting
MS24576-2
White lighting
MS24576-3
White lighting with multilayer coated antireflection cover glass
2. APPLICABLE DOCUMENTS
2.1 General. The documents listed in this section are specified in sections 3, 4, or 5 of this specification. This
section does not include documents cited in other sections of this specification or recommended for additional
information or as examples. While every effort has been made to ensure the completeness of this list, document
users are cautioned that they must meet all specified requirements of documents cited in sections 3, 4, or 5 of this
specification, whether or not they are listed.
2.2 Government documents.
2.2.1 Specifications, standards, and handbooks. The following specifications, standards, and handbooks form a
part of this document to the extent specified herein. Unless otherwise specified, the issues of these documents are
those cited in the solicitation or contract.
FEDERAL STANDARDS
FED-STD-595
Color Used in Government Procurement (Color Chips 37038 and 37875).
Comments, suggestions, or questions on this document should be addressed to: Oklahoma City Air Logistics
Center/ENEP, 3001 Staff Drive, Suite 2AG-68A, Tinker AFB, OK 73145-3036 or emailed to
ocalc.enrs.sma@tinker.af.mil. Since contact information can change, you may want to verify the currency of this
address information using the ASSIST database at https://assist.daps.dla.mil
AMSC N/A
FSC 6620
