MIL-DTL-38394E
3.4 Performance. The transmitter shall meet the performance requirements specified
herein and operate within the tolerances specified in table I.
TABLE I. Scale error tolerances.
Room
During/after
temperature,
reliability,
Scale
friction,
high and low temp
point
vibration,
exposure,
High and low
Pointer
1
psi
Deg
sensor match
overpressure
temperature
oscillation
Position error
0
20
3.0
4.5
3.75
2.25
50
52
3.5
5.25
4.5
2.75
100
84
4.0
6.0
5.0
3.0
150
116
4.5
6.75
5.5
3.5
200
148
5.0
7.5
6.25
3.75
250
180
5.5
8.25
7.0
4.25
5.0 (at mid scale)
300
212
6.0
9.0
7.5
4.5
400
276
7.0
10.5
8.75
5.25
500
340
8.0
12.0
10.0
6.0
1
Assumes indicating standard electrical zero in accordance with SAE-AS20708.
3.4.1 Temperature. The transmitter shall operate at temperatures ranging from -65 ºF to
329 ºF (-54 ºC to +165 ºC) and exposure to temperatures ranging from -79 ºF to +450 ºF (-62 ºC
to +232 ºC).
3.4.2 Vibration. The transmitter shall withstand vibration of 20 gravity (g) peak for
three hours on each axis.
3.4.3 Altitude-temperature. The transmitter shall withstand absolute pressure equivalent
to an 85,000-foot altitude at -65 ºF (-54 ºC).
3.4.4 Salt fog. The transmitter shall withstand exposure to salt sea atmosphere for
48 hours.
3.4.5 Overpressurization
3.4.5.1 Overpressure (750 psi). The transmitter shall withstand an overpressure of 750
psi for a 10 minute period.
3.4.5.2 Overpressure (1000 psi). The transmitter with a compromised case shall
withstand an overpressure of 1000 psi without leakage or failure.
3.4.6 Dielectric strength. The transmitter shall withstand 200 volts (Vac) at a
commercial frequency applied between any pin of the electrical connector not connected to the
case and the case for a minimum period of five seconds.
7
